SPECS
Sensor Type Sony 1/3" CMOS Sensor
Scale 4:3(Default)/16:9 Switchable
Tv System PAL(Default)/NTSC Switchable
Resolution 1200TVL
Lens M12 1.7mm
FOV 4:3 FOV-H: 138° FOV-D:172° / 16:9 FOV-H: 138° FOV-D:158°
Shutter Speed PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec
Video Output CVBS Analog Signal
Minimum Illumination 0.0001Lux
White Balance Auto
DNR 3DNR
WDR 100dB
DAY/NIGHT EXT/Auto/Color/B&W
Flight OSD Voltage/Cam Title/Time
Input Voltage 4.6V~20V
Language ENGLISH /??/ PYCCKNN / ESPANOL / ITALIANO /FRANCAIS/POLSKIM/ PORTUGUES / ??? / EAAHNIKA
Working Temperature -10°~50°C RH90% MAX
Working Humidity 20~80%
Storage Temperature -20°~70°C
Consumption 95mA±15% @ DC12V
Dimension 22*22mm; 28*22(with Bracket)
Weight 10.2g(Exclude cable)
