Features
5mm titanium alloy shaft, our strongest prop shaft ever!
Smooth and long-lasting NSK 10x4x4 bearings
Center slotted N52H curved arc magnets
XING O-ring bearing gap protection
Crash resistant 7075 aluminum bell
Motor wires protector
Dynamically balanced

Specifications
Model: XING2 2506 Black Motor
KV: 1500KV
Weight(included wire): 38.2g
Dimension: ?31.7*19.6mm
Interphase Resistance: 74.88m?
Input Volts: 25.2V
Peak Current: 33.26A
Max Watt: 817.5W
Mounting Holes: 16*16 ?3mm
Rotor Specifications: Unibell
Shaft Diameter: 5mm
Shaft Protruding Length: 15mm
Lead: 160mm-20AWG
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: ?10*?4*4
Winding: Single Strand copper winding

Packing List
1 x M5 Flanged Nylon Insert Lock Nut
1 x XING2 2506 Motor Black
4 x M3*8mm screws
