Discover the future of sub 250g FPV with the AOS 3.5 V5, engineered to revolutionize your freestyle experience. Designed with cutting-edge patent pending technology and premium materials, here's why the AOS 3.5 V5 is the ultimate choice for drone enthusiasts.

Features
Supports up to 3.5" Props
AOS X-Cell Anti-Vibration Technology
Up to two 25.5x25.5, or 20x20 mm stacks
155° FOV no props in view
Fully DJI O3 compatible (soft mount + ND filters)
Supports 19-20mm cameras (hard or soft mounted)
Reinforced 7075 Aluminium Camera Cage
Supports Lengthwise or Toilet Tank battery mounting
?9 - ?12mm motor mounting (supports all standard 3 - 4" motors)
27x21mm M2 GoPro Mounting Pattern
32mm Rear Standoff Spacing (compatible with all AOS 3.5 antenna mounts)

Specifications
Product Name: AOS 3.5 V5 Frame Kit
Frame wheelbase: 162mm
Frame Dimension: L133*W93*H30 mm
Arm Thickness: 4mm
Top Plate Thickness: 1.5mm
Bottom Plate Thickness: 1.5mm
Upper Plate Thickness: 2mm
Max Flight Stack Height: 20mm
Max VTX Height: 20mm
Motor Mounting: 9x9-?2mm/12x12-?2mm
Flight Stack Mounting: 20*20 ?2mm / 25.5*25.5 ?2mm
VTX Mounting: 20*20/?2mm / 25.5*25.5/?2mm
Weight: 68g
Compatible: DJI O3 air unit/ Vista HD system/ BLITZ Whoop 1.6W VTX

Packing List
1 x AOS 3.5 V5 Frame Kit
1 x TPU Parts
1 x Screw Bag
2 x Battery Strap
2 x Battery pads
